GIHRK120-DO-A Rod Ends GIHRK120DOA Ball diameter dK 160 mm Inside Ø, lower tolerance dUT -0.02 mm Radial Clearance Gr 0,065 - 0,165 Shank diameter, large d5 217 mm Distance drilling with/shaft start l7 140 mm Thread length Internal thread l3 135 mm Width of the rod end C1 90 mm...

GE200-FW-2RS-B Spherical Plain Bearings GE200FW2RSB Tilt angle α 15 ° Width, lower tolerance BUT -0.30 mm Inside Ø, lower tolerance dUT -0.03 mm Ball diameter dK 275 mm Outside diameter, lower tolerance Do UT -0.04 mm Radial Clearance Gr 0 - 0,1 Housing Connection Diameter Da min 267 mm Edge...

GAKL6-PB-A Rod Ends GAKL6PBA Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 6,930 Width B 9 mm Inside Ø d 6 mm Dynamic load rating Cr 4,320 Outside Ø D 16 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT 0.01 mm...

GAL60-UK-2RS-A Rod Ends GAL60UK2RSA Ball diameter dK 80 mm Inside Ø, lower tolerance dUT -0.02 mm Distance drilling with/shaft start l7 75 mm Tilt angle α 6 ° Shank Length External thread rod h 210 mm Outer flange diameter inner ring d1 66.80 mm Width, lower tolerance BUT -0.15 mm...

GE180-AW-B Spherical Plain Bearings GE180AWB Bore diameter of housing washer D1 224 mm Outer eye diameter d2 300 mm Width, lower tolerance BUT -0.50 mm Outside diameter, lower tolerance Do UT -0.04 mm Tilt angle α 8 ° Width Outer ring C 60 mm Front surface diameter of shaft washer...

GE140-DO-2RS-A Spherical Plain Bearings GE140DO2RSA Width Outer ring C 70 mm Radial Clearance Gr 0,085 - 0,165 Inside Ø, lower tolerance dUT -0.03 mm Tilt angle α 7 ° Width, lower tolerance BUT -0.25 mm Outside diameter, lower tolerance Do UT -0.03 mm Edge Spacing r1smin 1 mm Ball diameter...

GIHNRK160-LO-A Rod Ends GIHNRK160LOA Outer eye diameter d2 326 mm Ball diameter dK 200 mm Inside Ø, tolerance dT H7 Tightening torque MA 660 Nm Radial Clearance Gr 0,065 - 0,192 Width B 82 mm Welding Shank Diameter d 7 M24x80 Total length internal thread head l4 488 mm Tilt...

GIKL10-PB-A Rod Ends GIKL10PBA Main & Performance Data Radial Clearance Gr 0 - 0,035 Dynamic load rating Cr 10,000 Outside Ø D 22 mm Static load rating C0r 18,500 Width B 14 mm Inside Ø d 10 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT 0.02...

GE160-LO-A Spherical Plain Bearings GE160LOA Ball diameter dK 200 mm Width, lower tolerance BUT -0.40 mm Outside diameter, lower tolerance Do UT -0.03 mm Edge Spacing r1smin 1 mm Width Outer ring C 80 mm Radial Clearance Gr 0,1 - 0,192 Inside Ø, upper tolerance dOT 0.04 mm Tilt angle...

GE120-DO-2RS-A-C3 Spherical Plain Bearings GE120DO2RSAC3 Ball diameter dK 160 mm Width, lower tolerance BUT -0.20 mm Outside diameter, lower tolerance Do UT -0.03 mm Edge Spacing r1smin 1 mm Width Outer ring C 70 mm Radial Clearance Gr 0,085 - 0,165 Inside Ø, lower tolerance dUT -0.02 mm Tilt angle...

GE28-SW-A Spherical Plain Bearings GE28SWA Plane Surface Spacing s 1 mm Bore diameter of housing washer D1 35.70 mm Width, lower tolerance BUT -0.24 mm Height, upper tolerance TOT 0.25 mm Inside Ø, lower tolerance dUT -0.01 mm Width Outer ring C 15 mm Ball diameter dK 47 mm Height,...

GE360-DW-B-XL Spherical Plain Bearings GE360DWBXL Radial Clearance Gr 0 - 0,135 Ball diameter dK 420 mm Outside diameter, lower tolerance Do UT -0.05 mm Tilt angle α 3.60 ° Width, lower tolerance BUT -0.40 mm Inside Ø, lower tolerance dUT -0.04 mm Housing Connection Diameter Da min 403 mm Edge...
