GIHNRK40-LO Rod Ends GIHNRK40LO Outer flange diameter inner ring d1 46 mm Width, lower tolerance BUT -0.25 mm Inside Ø, upper tolerance dOT 0.03 mm Cylinder Force FZ 80,000 Edge Spacing r1smin 0.60 mm Shank diameter, large d5 80 mm Distance drilling with/shaft start l7 41 mm Thread length Internal...
GIHNRK20-LO Rod Ends GIHNRK20LO Outer flange diameter inner ring d1 25 mm Width, lower tolerance BUT -0.21 mm Inside Ø, upper tolerance dOT 0.02 mm Cylinder Force FZ 20,000 Edge Spacing r1smin 0.30 mm Shank diameter, large d5 47 mm Distance drilling with/shaft start l7 22 mm Thread length Internal...
GIHNRK16-LO Rod Ends GIHNRK16LO Outer flange diameter inner ring d1 20 mm Width, lower tolerance BUT -0.18 mm Inside Ø, upper tolerance dOT 0.02 mm Cylinder Force FZ 12,500 Edge Spacing r1smin 0.30 mm Shank diameter, large d5 40 mm Distance drilling with/shaft start l7 18 mm Thread length Internal...
GE60-SW-A Spherical Plain Bearings 60x95x23 mm GE60SWA Bore diameter of housing washer D1 68.10 mm Width, lower tolerance BUT -0.30 mm Height, upper tolerance TOT 0.25 mm Inside Ø, lower tolerance dUT -0.02 mm Plane Surface Spacing s 5 mm Ball diameter dK 86 mm Height, lower tolerance TUT -0.25...
GIHNRK12-LO Rod Ends GIHNRK12LO Outer flange diameter inner ring d1 15.50 mm Width, lower tolerance BUT -0.18 mm Inside Ø, upper tolerance dOT 0.02 mm Cylinder Force FZ 8,000 Edge Spacing r1smin 0.30 mm Shank diameter, large d5 32 mm Distance drilling with/shaft start l7 14 mm Thread length Internal...
GIHNRK110-LO Rod Ends 110x235x62 mm GIHNRK110LO Main & Performance Data Static load rating C0r 1,100,000 Width, B 110 mm Inside Ø d 110 mm Dynamic load rating Cr 655,000 Outside Ø D 160 mm Width, lower tolerance BUT -0.35 mm Inside Ø, upper tolerance dOT 0.04 mm Cylinder Force FZ...
GE40-SW-A Spherical Plain Bearings 40x68x19 mm GE40SWA Bore diameter of housing washer D1 46.80 mm Width, lower tolerance BUT -0.24 mm Height, upper tolerance TOT 0.25 mm Inside Ø, lower tolerance dUT -0.01 mm Plane Surface Spacing s 1.50 mm Ball diameter dK 60 mm Height, lower tolerance TUT -0.25...
GIHNRK100-LO Rod Ends 100x210x62 mm GIHNRK100LO Main & Performance Data Static load rating C0r 840,000 Width, B 100 mm Inside Ø d 100 mm Dynamic load rating Cr 608,000 Outside Ø D 150 mm Width, lower tolerance BUT -0.35 mm Inside Ø, upper tolerance dOT 0.04 mm Cylinder Force FZ...
GE30-AW-A Spherical Plain Bearings 30x75x26 mm GE30AWA Outer eye diameter d2 69 mm Width, lower tolerance BUT -0.24 mm Outside diameter, lower tolerance Do UT -0.01 mm Tilt angle α 6 ° Width Outer ring C 19.50 mm Front surface diameter of shaft washer d3 56 mm Ball diameter dK...
