GIHRK110 -DO Rod Ends GIHRK110 DO Outer flange diameter inner ring d1 121.20 mm Width, lower tolerance BUT -0.20 mm Tightening torque MA 385 Nm Edge Spacing r1smin 1 mm Welding Shank Diameter d 7 M20x70 Total length internal thread head l4 407.50 mm Tilt angle α 6 ° Shank...

GE110-FW-2RS Spherical Plain Bearings GE110FW2RS Tilt angle α 12 ° Width, lower tolerance BUT -0.20 mm Inside Ø, lower tolerance dUT -0.02 mm Ball diameter dK 160 mm Outside diameter, lower tolerance Do UT -0.03 mm Radial Clearance Gr 0 - 0,085 Housing Connection Diameter Da min 150 mm Edge...

GE25-PB Spherical Plain Bearings 25x47x31 mm GE25PB Width Outer ring C 22 mm Radial Clearance Gr 0,006 - 0,035 Inside Ø, tolerance dT H7 Edge Spacing r1smin 0.60 mm Ball diameter dK 42.85 mm Width, lower tolerance BUT -0.12 mm Outside diameter, lower tolerance Do UT -0.01 mm Inside Ø,...

GAKRB18-PD Rod Ends 18x46x23 mm GAKRB18PD

GAKL8-PW-A Rod Ends GAKL8PWA Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 12,900 Width B 12 mm Outside Ø D 19 mm Inside Ø d 8 mm Dynamic load rating Cr 12,900 Total length external thread rod l2 54 mm Outer eye diameter d2 24...

GIL8-DO Rod Ends 8x24x48 mm GIL8DO Main & Performance Data Radial Clearance Gr 0,023 - 0,068 Dynamic load rating Cr 5,590 Outside Ø D 16 mm Static load rating C0r 16,000 Width B 8 mm Inside Ø d 8 mm Width, lower tolerance BUT -0.12 mm Width Across Flat W...

GAKL16-PB Rod Ends 16x42x21 mm GAKL16PB Outer flange diameter inner ring d1 19.30 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT 0.02 mm Distance drilling with/shaft start l7 23 mm Shank Length External thread head l1 37 mm Width of the rod end C1 15 mm...

GIR50DO-2RS Rod Ends 50x114x35 mm GIR50DO2RS Outer flange diameter inner ring d1 55.90 mm Width, lower tolerance BUT -0.12 mm Width Across Flat W 65 mm Width of the rod end C1 30 mm Distance drilling with/shaft start l7 60 mm Total length internal thread head l4 216 mm Tilt...

GIKR14-PW-A Rod Ends 14x38x19 mm GIKR14PWA Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 32,000 Width B 19 mm Inside Ø d 14 mm Dynamic load rating Cr 31,000 Outside Ø D 28 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT...

GE80-SW-A Spherical Plain Bearings 80x125x29 mm GE80SWA Bore diameter of housing washer D1 90.50 mm Width, lower tolerance BUT -0.30 mm Height, upper tolerance TOT 0.25 mm Inside Ø, lower tolerance dUT -0.02 mm Plane Surface Spacing s 10 mm Ball diameter dK 115 mm Height, lower tolerance TUT -0.25...

GAR20-UK Rod Ends 20x53x16 mm GAR20UK Outer flange diameter inner ring d1 24.10 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0 - 0,04 Thread length external thread l1 43 mm Width of the rod end C1 13 mm Thread size d3 M20x1,5 Ball diameter dK 29 mm...

GIL20-UK Rod Ends 20x53x103.50 mm GIL20UK Outer flange diameter inner ring d1 24.10 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0 - 0,04 Shank diameter, large d5 35 mm length rod end shank l5 10 mm Thread length Internal thread l3 40 mm Width of the rod...
