5213-2RSTNC3 NSK Double Row Angular Contact Ball Bearings Features & Specifications:
operating temperature range : Maximum of +250 °F
outside diameter : 120 mm
Bore Diameter : 65 mm
cage material : Synthetic Resin
overall width : 1.5000 in
outer ring width : 38.1 mm
contact angle : 25 °
maximum rpm : 4500 RPM
row type & fill slot : Double-Row Non-Fill Slot
finish/coating : Uncoated
internal clearance : C3
precision rating : ABEC 1 (ISO Class Normal)
fillet radius : 1.5 mm
closure type : Double Seal
radial dynamic load capacity : 7800 kgf
Series : 52
Radial static load capacity : 7050 kgf
