5313-2RSNRTNC3 NSK Double Row Angular Contact Ball Bearings Features & Specifications:
finish/coating : Uncoated
internal clearance : C3
precision rating : ABEC 1 (ISO Class Normal)
closure type : Double Seal
fillet radius : 2 mm
radial dynamic load capacity : 14500 kgf
Series : 53
Bore Diameter : 65 mm
operating temperature range : Maximum of +250 °F
outside diameter : 140 mm
cage material : Synthetic Resin
overall width : 2.3125 in
outer ring width : 58.7 mm
contact angle : 25 °
maximum rpm : 4300 RPM
row type & fill slot : Double-Row Non-Fill Slot
Radial static load capacity : 11500 kgf
