5313-2RSTNGC3 NSK Double Row Angular Contact Ball Bearings Features & Specifications:
snap ring included : Without Snap Ring
radial dynamic load capacity : 155000 N
Bore Diameter : 65 mm
outside diameter : 140 mm
overall width : 2.3125 in
maximum temperature : 120 °C
contact angle : 25 °
cage material : Polyamide Cage
row type & fill slot : Double-Row Non-Fill Slot
finish/coating : Uncoated
internal clearance : C3
precision rating : ABEC1, P0
bore type : Round
fillet radius : 2.1 mm
closure type : Sealed
Series : 5300
