DSP5FS464 FIJ Double-Row Self-Aligning Ball Features & Specifications:
cage material : No Cage
finish/coating : Cadmium Plated
Bore Diameter : 0.3125 in
outside diameter : 1.2500 in
overall width : 0.8120 in
maximum misalignment : 10 °
bore type : Straight
application : Airframe Control
closure type : Double Sealed
outer ring width : 16.66 mm
internal clearance : C0
inner ring width : 20.62 mm
precision rating : Not Rated
Series : DSP
bearing material : Steel
standards met : SAE-AS7949, AISI 52100, MIL-PRF-81322
