DSP6FS428 FIJ Double-Row Self-Aligning Ball Features & Specifications:
Bore Diameter : 0.3750 in
cage material : No Cage
outside diameter : 1.4375 in
finish/coating : Cadmium Plated
overall width : 0.9370 in
bore type : Straight
maximum misalignment : 10 °
application : Airframe Control
closure type : Double Sealed
outer ring width : 19.05 mm
inner ring width : 23.8 mm
internal clearance : C0
precision rating : Not Rated
Series : DSP
bearing material : Steel
standards met : SAE-AS7949, MIL-PRF-23827, AISI 52100
