R4-2Z Deep Groove Ball Bearings Radial Ball Bearings R4-ZZ
The price is FOB CHINA, Brand(Manufacturer): FIJ
Payment Terms: T/T or paypal or western union.
Package: Standard or According to your requirements.
Bearing shop online - Best Bearings Supplier In China
Not all bearings are equal, and not all bearings can work freely. But with the right bearings, you can make your machine worry-free working. Being one of the best Bearings suppliers in China, we can offer you the right bearings based on your needs.
if you need support on selection of bearings,contact us at info@bearingshop.org
R4-2Z Deep Groove Ball Bearings Radial Ball Bearings R4-ZZ Dimensions
| Attributes | Values |
| Bearing Type | Sealed |
| Bore Dia (d) | 0.2500 |
| Outer Dia (D) | 0.6250 |
| Width (B) | 0.1960 |
| Radius (min) (rs) | 0.002 |
| Dynamic Load Rating (Cr) | 333 |
| Static Load Rating (Cor) | 131 |
| Max Speed (Grease) (X1000 RPM) | 38 |
| Max Speed (Oil) (X1000 RPM) | 45 |
| Max. Shaft Shoulder Dia. Inner (Ui) | 0.3 |
| Min. Housing Shoulder Dia., Outer (Uo) | 0.534 |
| Ball Qty | 8 |
| Ball Dia (Dw) | 0.0937 |
| Weight (g) | 4.54 |
| Precision | A1 |
| Standard Clearance | K25 |
| Material | 52100 Chrome steel (or equivalent) |
