KRE80-PP-A-NMT Stud type track rollers bearings

KR19-PP-SK-A-NMT Stud type track rollers bearings

LR5306-2Z Track rollers bearings

KRV72-PP-A-NMT Stud type track rollers bearings

KR40-X-NMT Stud type track rollers bearings Dimensions Maximum witdh of thrust washer B1 21.60 mm Width of flats W 8 mm Thread M18X1,5 Stop diameter of thrust washer d2 31.50 mm Protrusion outer ring to thrust washer C1 0.80 mm Distance to lubrication hole Ca 8 mm Radius of outer...

LR5306-2RS Track rollers bearings

NATV35-PP-A Track rollers bearings Dimensions Width, outer ring C 28 mm Outside diameter of thrust washer d2 58 mm Minimum chamfer dimension rmin 1.10 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 62,000 N Speed on permanent grease lubrication nD G 750 1/min Basic...

KRE52-PP Stud type track rollers bearings Main Dimensions & Performance Data Speed on permanent grease lubrication nD G 2,400 1/min Basic static load rating, radial C0r 29,500 N Width B 66 mm Outside diameter D 52 mm Fatigue load limit, radial Cur 3,850 N Basic dynamic load rating, radial Cr...

LR5201-2HRS-TVH-XL Track rollers bearings Dimensions Diameter of thrust washer d2 19.10 mm Minimum chamfer dimension rmin 0.60 mm Radius of outer ring outside profile R 500 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 4,800 N Fatigue load limit, radial Cur 315 N Basic...

LR5307-2RS Track rollers bearings

NUKR40 Stud type track rollers bearings Dimensions Witdh of thrust washer B1 21.60 mm Thread length IG 19 mm Diameter lubrication hole ds 3 mm Minimum chamfer dimension rmin 1 mm Width, outer ring C 20 mm Bolt/stud length effectively B2 36.50 mm Width of flats W 8 mm Thread...

LR5200-2RS Track rollers bearings

KRV22-PP-A-NMT Stud type track rollers bearings

LR5308-2Z Track rollers bearings

LR203-X-2RS Track rollers bearings

NATV25PP Track rollers bearings Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 43,500 N Speed on permanent grease lubrication nD G 1,000 1/min Basic static load rating, radial C0r 44,500 N Width, inner ring Bi 25 mm Bore diameter d 25 mm Permissible static load,...

KRV80-PP Stud type track rollers bearings Dimensions Witdh of thrust washer B1 37 mm Thread length IG 32 mm Diameter lubrication hole ds 4 mm Minimum chamfer dimension rmin 1.10 mm Width, outer ring C 35 mm Bolt/stud length effectively B2 63 mm Width of flats W 14 mm Thread...

KR5203-2RS Track rollers bearings Dimensions Maximum witdh of thrust washer B1 18.50 mm Width of flats W 8 mm Thread M18X1,5 Stop diameter of thrust washer d2 22.90 mm Width, outer ring C 17.50 mm Radius of outer ring outside profile R 500 mm Thread length IG 21 mm Minimum...

KRV62-PP Stud type track rollers bearings Dimensions Witdh of thrust washer B1 30.60 mm Thread length IG 25 mm Diameter lubrication hole ds 4 mm Minimum chamfer dimension rmin 1 mm Width, outer ring C 29 mm Bolt/stud length effectively B2 49.50 mm Width of flats W 14 mm Thread...

KR30-X Stud type track rollers bearings Dimensions Maximum witdh of thrust washer B1 15.20 mm Width of flats W 6 mm Thread M12X1,5 Stop diameter of thrust washer d2 23 mm Protrusion outer ring to thrust washer C1 0.60 mm Distance to lubrication hole Ca 6 mm Radius of outer...

LR5201-X-2Z-TVH-XL Track rollers bearings Dimensions Diameter of thrust washer d2 19.10 mm Minimum chamfer dimension rmin 0.60 mm Radius of outer ring outside profile R 500 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 4,800 N Fatigue load limit, radial Cur 315 N Basic...

KR62-PP Stud type track rollers bearings Main Dimensions & Performance Data Speed on permanent grease lubrication nD G 1,900 1/min Basic static load rating, radial C0r 48,500 N Width B 80 mm Outside diameter D 62 mm Fatigue load limit, radial Cur 7,000 N Basic dynamic load rating, radial Cr...

NATV20-PP-A Track rollers bearings Dimensions Width, outer ring C 24 mm Outside diameter of thrust washer d2 36.50 mm Minimum chamfer dimension rmin 1 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 42,500 N Speed on permanent grease lubrication nD G 1,300 1/min Basic...

KR26-PP Stud type track rollers bearings Main Dimensions & Performance Data Speed on permanent grease lubrication nD G 8,000 1/min Basic static load rating, radial C0r 6,500 N Width B 36 mm Outside diameter D 26 mm Fatigue load limit, radial Cur 860 N Basic dynamic load rating, radial Cr...
