GE20-UK Spherical Plain Bearings 20x35x16 mm GE20UK Radial Clearance Gr 0 - 0,04 Ball diameter dK 29 mm Outside diameter, lower tolerance Do UT -0.01 mm Tilt angle α 9 ° Width, lower tolerance BUT -0.12 mm Inside Ø, lower tolerance dUT -0.01 mm Housing Connection Diameter Da min 27.50...

GAKR10-PB Rod Ends 10x28x14 mm GAKR10PB Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 18,500 Width B 14 mm Inside Ø d 10 mm Dynamic load rating Cr 10,000 Outside Ø D 22 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT...

GIKR8-PW Rod Ends 8x24x48 mm GIKR8PW Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 13,100 Width B 12 mm Inside Ø d 8 mm Dynamic load rating Cr 12,900 Outside Ø D 19 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT...

Bearings Info Inner diameter(mm): 100.00 &nbsp Outer diameter(mm): 154.00 &nbsp Width(mm): 126.00 &nbsp Weight(g): 2,648.00 H2322 EE: Verstärkte Ausführung In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.H2322 E Adapter sleeves 100.00 x 154.00 x 126.00 mm

Bearings Info Inner diameter(mm): 20.00 &nbsp Outer diameter(mm): 38.00 &nbsp Width(mm): 29.00 &nbsp Weight(g): 77.00 In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.H305 C Adapter sleeves 20.00 x 38.00 x 29.00 mm

GAKR18-PB Rod Ends GAKR18PB Ball diameter dK 31.75 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0 - 0,035 Total length external thread head l2 95 mm Tilt angle α 15 ° Shank Length External thread rod h 72 mm Outer eye diameter d2 46 mm Width, lower tolerance...

GIKR18-PB Rod Ends GIKR18PB Ball diameter dK 31.75 mm Inside Ø, tolerance dT H7 Width Across Flat W 27 mm Width of the rod end C1 16.50 mm Distance drilling with/shaft start l7 23 mm Total length internal thread head l4 94.50 mm Tilt angle α 15 ° Shank diameter...

GIKR18-PW Rod Ends GIKR18PW Ball diameter dK 31.75 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0 - 0,035 Shank diameter, large d5 31 mm length rod end shank l5 10 mm Thread length Internal thread l3 32 mm Width of the rod end C1 16.50 mm Shank diameter...

GIKR22-PW Rod Ends GIKR22PW Ball diameter dK 38.10 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0 - 0,035 Shank diameter, large d5 38 mm length rod end shank l5 12 mm Thread length Internal thread l3 37 mm Width of the rod end C1 20 mm Shank diameter...

GAKR30-PB Rod Ends 30x70x37 mm GAKR30PB Outer flange diameter inner ring d1 34.80 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT 0.02 mm Distance drilling with/shaft start l7 37 mm Shank Length External thread head l1 66 mm Width of the rod end C1 25 mm...

GAR80-UK-2RS Rod Ends 80x180x55 mm GAR80UK2RS Edge Spacing r1smin 1 mm Main & Performance Data Static load rating C0r 690,000 Width B 55 mm Outside Ø D 120 mm Inside Ø d 80 mm Dynamic load rating Cr 1,130,000 Total length external thread rod l2 360 mm Outer eye diameter...

GE30-UK Spherical Plain Bearings 30x47x22 mm GE30UK Radial Clearance Gr 0 - 0,05 Ball diameter dK 40.70 mm Outside diameter, lower tolerance Do UT -0.01 mm Tilt angle α 6 ° Width, lower tolerance BUT -0.12 mm Inside Ø, lower tolerance dUT -0.01 mm Housing Connection Diameter Da min 38...

GIHNRK20-LO Rod Ends GIHNRK20LO Outer flange diameter inner ring d1 25 mm Width, lower tolerance BUT -0.21 mm Inside Ø, upper tolerance dOT 0.02 mm Cylinder Force FZ 20,000 Edge Spacing r1smin 0.30 mm Shank diameter, large d5 47 mm Distance drilling with/shaft start l7 22 mm Thread length Internal...

GIL30-DO Rod Ends 30x73x146.50 mm GIL30DO Main & Performance Data Radial Clearance Gr 0,037 - 0,1 Dynamic load rating Cr 62,300 Outside Ø D 47 mm Static load rating C0r 119,000 Width B 22 mm Inside Ø d 30 mm Width, lower tolerance BUT -0.12 mm Width Across Flat W...

Bearings Info Inner diameter(mm): 40.00 &nbsp Outer diameter(mm): 65.00 &nbsp Width(mm): 39.00 &nbsp Weight(g): 239.00 In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.H309 C Adapter sleeves 40.00 x 65.00 x 39.00 mm

GIR35-DO-2RS Rod Ends 35x84x25 mm GIR35DO2RS Main & Performance Data Radial Clearance Gr 0,037 - 0,1 Dynamic load rating Cr 79,900 Outside Ø D 55 mm Static load rating C0r 159,000 Width B 25 mm Inside Ø d 35 mm Width, lower tolerance BUT -0.12 mm Width Across Flat W...

GIHRK70-DO Rod Ends 70x154x232 mm GIHRK70DO Main & Performance Data Static load rating C0r 441,000 Width, B 49 mm Inside Ø d 70 mm Dynamic load rating Cr 313,000 Outside Ø D 105 mm Width, lower tolerance BUT -0.15 mm Tightening torque MA 80 Nm Edge Spacing r1smin 1 mm...

Bearings Info Inner diameter(mm): 30.00 &nbsp Weight(g): 1,050.00 In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.SY30 TF/VA201 Plummer block housing units 30.00 x 0.00 x 0.00 mm

Bearings Info Inner diameter(mm): 100.00 &nbsp Outer diameter(mm): 145.00 &nbsp Width(mm): 77.00 &nbsp Weight(g): 2,115.00 H322 EE: Verstärkte Ausführung In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.H322 E Adapter sleeves 100.00 x 145.00 x 77.00 mm

GE80-DO-2TS Spherical Plain Bearings 80x120x55,00 mm GE80DO2TS Brand Bearing Number SKF GE80 ES-2LS (SKF)

Bearings Info Inner diameter(mm): 50.00 &nbsp Outer diameter(mm): 81.00 &nbsp Width(mm): 49.50 &nbsp Weight(g): 300.00 In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.HA211 Adapter sleeves 50.00 x 81.00 x 49.50 mm

GIL50-DO-2RS Rod Ends 50x112x216 mm GIL50DO2RS Outer flange diameter inner ring d1 55.90 mm Width, lower tolerance BUT -0.12 mm Width Across Flat W 65 mm Width of the rod end C1 30 mm Distance drilling with/shaft start l7 60 mm Total length internal thread head l4 216 mm Tilt...

GF50-DO Rod Ends 50x123x149.50 mm GF50DO Edge Spacing r1smin 0.60 mm Main & Performance Data Radial Clearance Gr 0,043 - 0,12 Dynamic load rating Cr 157,000 Outside Ø D 75 mm Static load rating C0r 442,000 Width B 35 mm Inside Ø d 50 mm Width, lower tolerance BUT -0.12...

GAR60-UK-2RS Rod Ends 60x135x44 mm GAR60UK2RS Edge Spacing r1smin 1 mm Main & Performance Data Static load rating C0r 485,000 Width B 44 mm Outside Ø D 90 mm Inside Ø d 60 mm Dynamic load rating Cr 691,000 Total length external thread rod l2 277.50 mm Outer eye diameter...
