GAR40-UK-2RS Rod Ends 40x92x28 mm GAR40UK2RS Edge Spacing r1smin 0.60 mm Main & Performance Data Static load rating C0r 194,000 Width B 28 mm Outside Ø D 62 mm Inside Ø d 40 mm Dynamic load rating Cr 280,000 Total length external thread rod l2 196 mm Outer eye diameter...

GAR25-DO Rod Ends 25x64x20 mm GAR25DO Outer flange diameter inner ring d1 29.30 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0,037 - 0,1 Total length external thread head l2 126 mm Tilt angle α 7 ° Shank Length External thread rod h 94 mm Outer eye diameter...

GAL25-UK Rod Ends 25x64x20 mm GAL25UK Outer flange diameter inner ring d1 29.30 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0 - 0,05 Thread length external thread l1 53 mm Width of the rod end C1 17 mm Thread size d3 M24x2 Ball diameter dK 35.50 mm...

GIHRK20-DO Rod Ends 20x56x78 mm GIHRK20DO Main & Performance Data Static load rating C0r 81,100 Width, B 16 mm Inside Ø d 20 mm Dynamic load rating Cr 29,600 Outside Ø D 35 mm Width, lower tolerance BUT -0.12 mm Tightening torque MA 32 Nm Edge Spacing r1smin 0.30 mm...

GIKL20-PW Rod Ends 20x50x25 mm GIKL20PW Outer flange diameter inner ring d1 24.30 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT 0.02 mm Width Across Flat W 30 mm Distance drilling with/shaft start l7 26 mm Total length internal thread head l4 102 mm Tilt angle...

GIL45-DO-2RS Rod Ends 45x102x196 mm GIL45DO2RS Outer flange diameter inner ring d1 50.70 mm Width, lower tolerance BUT -0.12 mm Width Across Flat W 60 mm Width of the rod end C1 27 mm Distance drilling with/shaft start l7 52 mm Total length internal thread head l4 196 mm Tilt...

GIL35-DO-2RS Rod Ends 35x82x166 mm GIL35DO2RS Outer flange diameter inner ring d1 39.70 mm Width, lower tolerance BUT -0.12 mm Width Across Flat W 50 mm Width of the rod end C1 21 mm Distance drilling with/shaft start l7 42 mm Total length internal thread head l4 166 mm Tilt...

GE40-UK-2TS Spherical Plain Bearings 40x62x28,00 mm GE40UK2TS Housing Connection Diameter Da min 51 mm Edge Spacing r1smin 1 mm Connection measure Inner ring da max 45 mm Main & Performance Data Static load rating C0r 466,000 Width Outer ring C 22 mm Inside Ø d 40 mm Dynamic load rating...

GIR50-UK-2RS Rod Ends 50x112x216 mm GIR50UK2RS Edge Spacing r1smin 0.60 mm Main & Performance Data Static load rating C0r 314,000 Width B 35 mm Inside Ø d 50 mm Dynamic load rating Cr 444,000 Outside Ø D 75 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0 -...

GIR25-UK Rod Ends 25x64x126 mm GIR25UK Outer flange diameter inner ring d1 29.30 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0 - 0,05 Shank diameter, large d5 42 mm length rod end shank l5 12 mm Thread length Internal thread l3 48 mm Width of the rod...

GIKR16-PW Rod Ends 16x42x85 mm GIKR16PW Outer flange diameter inner ring d1 19.30 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT 0.02 mm Width Across Flat W 22 mm Distance drilling with/shaft start l7 23 mm Total length internal thread head l4 85 mm Tilt angle...

GK45DO Rod Ends 45x104x32 mm GK45DO Edge Spacing r1smin 0.60 mm Main & Performance Data Radial Clearance Gr 0,043 - 0,12 Dynamic load rating Cr 128,000 Outside Ø D 68 mm Static load rating C0r 208,000 Width, B 32 mm Inside Ø d 45 mm Width, lower tolerance BUT -0.12...

NUKRE52-X Stud type track rollers bearings Manufacturer Part Number LI-BE CFE52CZZ SKF NUKRE52X

NUKRE47-X Stud type track rollers bearings Manufacturer Part Number SKF NUKRE47X

GAL60-DO-2RS Rod Ends 60x1,350x44 mm GAL60DO2RS Edge Spacing r1smin 1 mm Main & Performance Data Static load rating C0r 485,000 Width B 44 mm Inside Ø d 60 mm Dynamic load rating Cr 245,000 Outside Ø D 90 mm Width, lower tolerance BUT -0.15 mm Radial Clearance Gr 0,043 -...

GAL25-DO Rod Ends 25x64x20 mm GAL25DO Outer flange diameter inner ring d1 29.30 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0,037 - 0,1 Total length external thread head l2 126 mm Tilt angle α 7 ° Shank Length External thread rod h 94 mm Outer eye diameter...

GAKL20-PW Rod Ends GAKL20PW Ball diameter dK 34.93 mm Inside Ø, upper tolerance dOT 0.02 mm Radial Clearance Gr 0 - 0,035 Thread length external thread l1 45 mm Width of the rod end C1 18 mm Thread size d3 M20x1,5 Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance...

GIKR22-PB Rod Ends GIKR22PB Ball diameter dK 38.10 mm Inside Ø, tolerance dT H7 Width Across Flat W 32 mm Width of the rod end C1 20 mm Distance drilling with/shaft start l7 27 mm Total length internal thread head l4 111.50 mm Tilt angle α 15 ° Shank diameter...

Bearings Info Inner diameter(mm): 25.40 &nbsp Outer diameter(mm): 45.00 &nbsp Width(mm): 27.00 &nbsp Weight(g): 91.00 In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.HE206 Adapter sleeves 25.40 x 45.00 x 27.00 mm

GAL50-DO-2RS Rod Ends 50x112x35 mm GAL50DO2RS Outer flange diameter inner ring d1 55.90 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0,043 - 0,12 Total length external thread head l2 241 mm Tilt angle α 6 ° Shank Length External thread rod h 185 mm Outer eye diameter...

GAL45-DO-2RS Rod Ends 45x102x32 mm GAL45DO2RS Outer flange diameter inner ring d1 50.70 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0,043 - 0,12 Total length external thread head l2 214 mm Tilt angle α 7 ° Shank Length External thread rod h 163 mm Outer eye diameter...

Bearings Info Inner diameter(mm): 45.00 &nbsp Outer diameter(mm): 74.00 &nbsp Width(mm): 47.00 &nbsp Weight(g): 272.00 In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.HE210 Adapter sleeves 45.00 x 74.00 x 47.00 mm

GK25-DO Rod Ends 25x64x77 mm GK25DO Edge Spacing r1smin 0.60 mm Main & Performance Data Radial Clearance Gr 0,037 - 0,1 Dynamic load rating Cr 48,300 Outside Ø D 42 mm Static load rating C0r 70,800 Width, B 20 mm Inside Ø d 25 mm Width, lower tolerance BUT -0.12...

GIKL16-PW Rod Ends 16x42x21 mm GIKL16PW Outer flange diameter inner ring d1 19.30 mm Width, lower tolerance BUT -0.12 mm Inside Ø, upper tolerance dOT 0.02 mm Width Across Flat W 22 mm Distance drilling with/shaft start l7 23 mm Total length internal thread head l4 85 mm Tilt angle...
