GIHNRK110-LO-A Rod Ends GIHNRK110LOA Outer flange diameter inner ring d1 124 mm Width, lower tolerance BUT -0.35 mm Inside Ø, upper tolerance dOT 0.04 mm Cylinder Force FZ 635,000 Edge Spacing r1smin 1 mm Shank diameter, large d5 190 mm Distance drilling with/shaft start l7 105 mm Thread length Internal...

GIHRK90-DO-A Rod Ends GIHRK90DOA Ball diameter dK 115 mm Inside Ø, lower tolerance dUT -0.02 mm Radial Clearance Gr 0,055 - 0,142 Shank diameter, large d5 146 mm Distance drilling with/shaft start l7 90 mm Thread length Internal thread l3 101 mm Width of the rod end C1 65 mm...

GIL40-UK-2RS-A Rod Ends GIL40UK2RSA Ball diameter dK 53 mm Inside Ø, lower tolerance dUT -0.01 mm Width Across Flat W 55 mm Distance drilling with/shaft start l7 48 mm Total length internal thread head l4 188 mm Tilt angle α 7 ° Shank Length Internal thread head h1 142 mm...

GIKL6-PB-A Rod Ends GIKL6PBA Ball diameter dK 12.70 mm Inside Ø, tolerance dT H7 Width Across Flat W 11 mm Width of the rod end C1 6.75 mm Distance drilling with/shaft start l7 11 mm Total length internal thread head l4 40 mm Tilt angle α 13 ° Shank diameter...

GIL70-UK-2RS-A Rod Ends GIL70UK2RSA Ball diameter dK 92 mm Inside Ø, lower tolerance dUT -0.02 mm Width Across Flat W 85 mm Distance drilling with/shaft start l7 87 mm Total length internal thread head l4 280 mm Tilt angle α 6 ° Shank Length Internal thread head h1 200 mm...

GE180-FW-2RS-B Spherical Plain Bearings GE180FW2RSB Tilt angle α 14 ° Width, lower tolerance BUT -0.30 mm Inside Ø, lower tolerance dUT -0.03 mm Ball diameter dK 250 mm Outside diameter, lower tolerance Do UT -0.04 mm Radial Clearance Gr 0 - 0,1 Housing Connection Diameter Da min 239 mm Edge...

GAL6-DO Rod Ends GAL6DO Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 6,930 Width B 6 mm Inside Ø d 6 mm Dynamic load rating Cr 3,400 Outside Ø D 14 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0,023 - 0,068 Total...

GAKSL6-PS Rod Ends GAKSL6PS Outer flange diameter inner ring d1 9 mm Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Distance drilling with/shaft start l7 10 mm Tilt angle α 13 ° Shank Length External thread rod h 36 mm Ball diameter dK 12.70 mm Inside Ø,...

GAKSR16-PS Rod Ends GAKSR16PS Outer flange diameter inner ring d1 19.40 mm Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Distance drilling with/shaft start l7 21 mm Tilt angle α 15 ° Shank Length External thread rod h 66 mm Ball diameter dK 28.50 mm Inside Ø,...

GAKSL16-PS Rod Ends GAKSL16PS Outer flange diameter inner ring d1 19.40 mm Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Distance drilling with/shaft start l7 21 mm Tilt angle α 15 ° Shank Length External thread rod h 66 mm Ball diameter dK 28.50 mm Inside Ø,...

GAKSL12-PS Rod Ends GAKSL12PS Outer flange diameter inner ring d1 15.40 mm Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Distance drilling with/shaft start l7 16 mm Tilt angle α 13 ° Shank Length External thread rod h 54 mm Ball diameter dK 22.20 mm Inside Ø,...

GIKPR30-PW Rod Ends GIKPR30PW Ball diameter dK 50.80 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0 - 0,035 Shank diameter, large d5 50 mm length rod end shank l5 15 mm Thread length Internal thread l3 51 mm Width of the rod end C1 25 mm Shank diameter...
