GE6-PB Spherical Plain Bearings GE6PB Width Outer ring C 6.75 mm Radial Clearance Gr 0,006 - 0,035 Inside Ø, tolerance dT H7 Edge Spacing r1smin 0.30 mm Ball diameter dK 12.70 mm Width, lower tolerance BUT -0.12 mm Outside diameter, lower tolerance Do UT -0.01 mm Inside Ø, upper tolerance...

GAKR22-PW Rod Ends GAKR22PW Ball diameter dK 38.10 mm Inside Ø, upper tolerance dOT 0.02 mm Radial Clearance Gr 0 - 0,035 Thread length external thread l1 48 mm Width of the rod end C1 20 mm Thread size d3 M22x1,5 Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance...

GIKSR12-PS Rod Ends GIKSR12PS Ball diameter dK 22.20 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0,005 - 0,045 Shank diameter, large d5 22 mm length rod end shank l5 6.50 mm Thread length Internal thread l3 18 mm Width of the rod end C1 12 mm Shank diameter...

GAKSR10-PS Rod Ends GAKSR10PS Outer flange diameter inner ring d1 12.90 mm Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Distance drilling with/shaft start l7 14 mm Tilt angle α 13 ° Shank Length External thread rod h 48 mm Ball diameter dK 19 mm Inside Ø,...

GAKSL10-PS Rod Ends GAKSL10PS Outer flange diameter inner ring d1 12.90 mm Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Distance drilling with/shaft start l7 14 mm Tilt angle α 13 ° Shank Length External thread rod h 48 mm Ball diameter dK 19 mm Inside Ø,...

GIKSL25-PS Rod Ends GIKSL25PS Ball diameter dK 42.80 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0,010 - 0,055 Shank diameter, large d5 42 mm length rod end shank l5 12 mm Thread length Internal thread l3 36 mm Width of the rod end C1 22 mm Shank diameter...

GE25-SX Spherical Plain Bearings GE25SX Connection diameter Db min 43 mm Connection measure Inner ring da max 30.10 mm Housing Connection Diameter Da min 34 mm Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 239,000 Height T 15 mm Inner diameter bearing d 25 mm...

GAL70-DO-2RS Rod Ends GAL70DO2RS Ball diameter dK 92 mm Inside Ø, lower tolerance dUT -0.02 mm Distance drilling with/shaft start l7 87 mm Shank Length External thread head l1 125 mm Width of the rod end C1 42 mm Thread size d3 M56x4 Outer flange diameter inner ring d1 77.80...

GIKSR16-PS Rod Ends GIKSR16PS Ball diameter dK 28.50 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0,005 - 0,045 Shank diameter, large d5 27 mm length rod end shank l5 8 mm Thread length Internal thread l3 24 mm Width of the rod end C1 15 mm Shank diameter...

GAR70-DO-2RS Rod Ends GAR70DO2RS Edge Spacing r1smin 1 mm Main & Performance Data Static load rating C0r 564,000 Width B 49 mm Inside Ø d 70 mm Dynamic load rating Cr 313,000 Outside Ø D 105 mm Width, lower tolerance BUT -0.15 mm Radial Clearance Gr 0,055 - 0,142 Total...

GAKSR5-PS Rod Ends GAKSR5PS Outer flange diameter inner ring d1 7.70 mm Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Distance drilling with/shaft start l7 9 mm Tilt angle α 13 ° Shank Length External thread rod h 33 mm Ball diameter dK 11.10 mm Inside Ø,...

GIL10-UK Rod Ends GIL10UK Edge Spacing r1smin 0.30 mm Main & Performance Data Static load rating C0r 22,000 Width B 9 mm Inside Ø d 10 mm Dynamic load rating Cr 8,640 Outside Ø D 19 mm Width, lower tolerance BUT -0.12 mm Radial Clearance Gr 0 - 0,032 Shank...
