GK10-DO Rod Ends GK10DO Ball diameter dK 16 mm Inside Ø, lower tolerance dUT -0.01 mm Chamfer l8 2 mm Total length welding head l6 38.50 mm Width of the rod end C1 7 mm Welding Shank Diameter d 7 15 mm Outer flange diameter inner ring d1 13.20 mm...

GIL80-UK-2RS-A Rod Ends GIL80UK2RSA Ball diameter dK 105 mm Inside Ø, lower tolerance dUT -0.02 mm Width Across Flat W 100 mm Distance drilling with/shaft start l7 100 mm Total length internal thread head l4 320 mm Tilt angle α 6 ° Shank Length Internal thread head h1 230 mm...

GIHNRK70-LO Rod Ends GIHNRK70LO Outer flange diameter inner ring d1 79 mm Width, lower tolerance BUT -0.30 mm Inside Ø, upper tolerance dOT 0.03 mm Cylinder Force FZ 250,000 Edge Spacing r1smin 1 mm Shank diameter, large d5 135 mm Distance drilling with/shaft start l7 70 mm Thread length Internal...

GE70-DO-C2 Spherical Plain Bearings GE70DOC2 Ball diameter dK 92 mm Width, lower tolerance BUT -0.15 mm Outside diameter, lower tolerance Do UT -0.02 mm Edge Spacing r1smin 1 mm Width Outer ring C 40 mm Radial Clearance Gr 0,072 - 0,142 Inside Ø, lower tolerance dUT -0.02 mm Tilt angle...

GE160-FW-2RS-B Spherical Plain Bearings GE160FW2RSB Tilt angle α 16 ° Width, lower tolerance BUT -0.25 mm Inside Ø, lower tolerance dUT -0.03 mm Ball diameter dK 225 mm Outside diameter, lower tolerance Do UT -0.04 mm Radial Clearance Gr 0 - 0,1 Housing Connection Diameter Da min 219 mm Edge...

GE200-DO-C3 Spherical Plain Bearings GE200DOC3 Ball diameter dK 250 mm Width, lower tolerance BUT -0.30 mm Outside diameter, lower tolerance Do UT -0.04 mm Edge Spacing r1smin 1.10 mm Width Outer ring C 100 mm Radial Clearance Gr 0,1 - 0,192 Inside Ø, lower tolerance dUT -0.03 mm Tilt angle...

GE22-PW Spherical Plain Bearings GE22PW Tilt angle α 15 ° Width, lower tolerance BUT -0.12 mm Inside Ø, tolerance dT H7 Radial Clearance Gr 0,006 - 0,035 Ball diameter dK 38.10 mm Outside diameter, lower tolerance Do UT -0.01 mm Inside Ø, upper tolerance dOT 0.02 mm Housing Connection Diameter...

GE120-DO-2TS Spherical Plain Bearings GE120DO2TS Ball diameter dK 160 mm Width, lower tolerance BUT -0.20 mm Outside diameter, lower tolerance Do UT -0.03 mm Edge Spacing r1smin 1 mm Width Outer ring C 70 mm Radial Clearance Gr 0,085 - 0,165 Inside Ø, lower tolerance dUT -0.02 mm Tilt angle...

GE100-DO-C3 Spherical Plain Bearings GE100DOC3 Ball diameter dK 130 mm Width, lower tolerance BUT -0.20 mm Outside diameter, lower tolerance Do UT -0.02 mm Edge Spacing r1smin 1 mm Width Outer ring C 55 mm Radial Clearance Gr 0,085 - 0,165 Inside Ø, lower tolerance dUT -0.02 mm Tilt angle...

GIHRK50-DO-B Rod Ends GIHRK50DOB Outer flange diameter inner ring d1 56 mm Width, lower tolerance BUT -0.12 mm Tightening torque MA 110 Nm Edge Spacing r1smin 0.60 mm Welding Shank Diameter d 7 M12x35 Total length internal thread head l4 163 mm Tilt angle α 6 ° Shank Length Internal...

GE110-DO-C3 Spherical Plain Bearings GE110DOC3 Ball diameter dK 140 mm Width, lower tolerance BUT -0.20 mm Outside diameter, lower tolerance Do UT -0.03 mm Edge Spacing r1smin 1 mm Width Outer ring C 55 mm Radial Clearance Gr 0,085 - 0,165 Inside Ø, lower tolerance dUT -0.02 mm Tilt angle...

GK15-DO Rod Ends GK15DO Ball diameter dK 22 mm Inside Ø, lower tolerance dUT -0.01 mm Chamfer l8 2.50 mm Total length welding head l6 51 mm Width of the rod end C1 10 mm Welding Shank Diameter d 7 21 mm Outer flange diameter inner ring d1 18.40 mm...
