IKO Cam Follower ECC Collar Caged Crowned OD Hex Hole DBL Sealed 90mm OD 35mm W M30 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)45400 STATIC LOAD RATING (N)85100 DIMENSION B 37mm max CORNER RADIUS ( r ) mm (inch)1 DIMENSION H 17mm...
IKO Cam Follower ECC Collar Caged Hex Hole DBL Sealed 90mm OD 35mm W M30 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)45400 STATIC LOAD RATING (N)85100 DIMENSION B 37mm max CORNER RADIUS ( r ) mm (inch)1 DIMENSION H 17mm PERMISSIBLE STATIC...
IKO Roller Follower- Full Comp- Inch, CRY44VUU, Double Sealed, 2-3/4" OD, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)61400 OUTER RING CORNER RADIUS MIN. MM (INCH)2.381 (3/32) RETAINERNone BORE DIAMETER MILLIMETERS (INCH)19.050 (3/4) SHAFT DIA PRESS FIT (MM)19.058 to 19.068 SIDE PLATE OD (A) MM (INCH)43.3...
IKO Separable Roller Follower- Metric, NAST45ZZR, Crowned OD, Double Shielded, 45 mm Bore, 85 mm OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)37400 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)45 SHAFT DIA G6 FIT (MM)-0.009 to -0.025 SIDE PLATE...
IKO Cam Follower ECC Collar Full Comp Crowned OD Hex Hole DBL Sealed 62mm OD 29mm W M24 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)46600 STATIC LOAD RATING (N)92000 DIMENSION B 30.6mm max CORNER RADIUS ( r ) mm (inch)1 DIMENSION H...
IKO Roller Follower- Full Comp- Inch, CRY14V, 7/8" OD, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)8710 OUTER RING CORNER RADIUS MIN. MM (INCH)0.794 (1/32) RETAINERNone BORE DIAMETER MILLIMETERS (INCH)6.350 (1/4) SHAFT DIA PRESS FIT (MM)6.353 to 6.363 SIDE PLATE OD (A) MM (INCH)14.4 (.567) DESCRIPTIONRoller...
IKO Roller Follower- Full Comp- Inch, CRY64VUUR, Crowned OD, Double Sealed, 4" OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)142000 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERNone BORE DIAMETER MILLIMETERS (INCH)31.750 (1-1/4) SHAFT DIA PRESS FIT (MM)31.758 to 31.770 SIDE PLATE OD (A) MM...
IKO Separable Roller Follower- Metric, NAST25ZZR, Crowned OD, Double Shielded, 25 mm Bore, 52 mm OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)20800 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)25 SHAFT DIA G6 FIT (MM)-0.007 to -0.020 SIDE PLATE...
IKO Separable Roller Follower- Metric, NAST17ZZR, Crowned OD, Double Shielded, 17 mm Bore, 40 mm OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)17600 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)17 SHAFT DIA G6 FIT (MM)-0.006 to -0.017 SIDE PLATE...
IKO Cam Follower-INCH HD Full Comp Screwdriver Slot DBL Sealed 1-1/8" OD 5/8"W 5/8 - 18 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)13100 STATIC LOAD RATING (N)22700 DIMENSION B 17.9mm (0.70") CORNER RADIUS ( r ) mm (inch)1.588 (1/16) DIMENSION H -- DIMENSION g2...
IKO Cam Follower-INCH HD Full Comp Screwdriver Slot DBL Sealed 3-1/2" OD 2"W 1-3/4 - 12 UN THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)111000 STATIC LOAD RATING (N)239000 DIMENSION B 52.8mm (2.08") CORNER RADIUS ( r ) mm (inch)2.381 (3/32) DIMENSION H -- DIMENSION...
IKO Roller Follower- Full Comp- Inch, CRY16VUUR, Crowned OD, Double Sealed, 1" OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)13100 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERNone BORE DIAMETER MILLIMETERS (INCH)7.938 (5/16) SHAFT DIA PRESS FIT (MM)7.940 to 7.950 SIDE PLATE OD (A) MM...
IKO Cam Follower ECC Collar Full Comp Hex Hole DBL Sealed 35mm OD 18mm W M16 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)20700 STATIC LOAD RATING (N)37600 DIMENSION B 19.6mm max CORNER RADIUS ( r ) mm (inch)0.6 DIMENSION H 6mm PERMISSIBLE...
IKO Roller Follower- Full Comp- Inch, CRY20VUUR, Crowned OD, Double Sealed, 1-1/4" OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)23600 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERNone BORE DIAMETER MILLIMETERS (INCH)9.525 (3/8) SHAFT DIA PRESS FIT (MM)9.528 to 9.538 SIDE PLATE OD (A) MM...
IKO Separable Roller Follower- Metric, NAST12ZZUUR, Crowned OD, Double Sealed, 12 mm Bore, 32 mm OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)10500 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)12 SHAFT DIA G6 FIT (MM)-0.006 to -0.017 SIDE PLATE...
IKO Roller Follower- Full Comp- Inch, CRY36VUU, Double Sealed, 2-1/4" OD, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)45700 OUTER RING CORNER RADIUS MIN. MM (INCH)1.588 (1/16) RETAINERNone BORE DIAMETER MILLIMETERS (INCH)15.875 (5/8) SHAFT DIA PRESS FIT (MM)15.883 to 15.893 SIDE PLATE OD (A) MM (INCH)36.0...
IKO Cam Follower-INCH HD Full Comp Screwdriver Slot DBL Sealed 5/8" OD 7/16"W 5/16 - 24 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)6340 STATIC LOAD RATING (N)8530 DIMENSION B 12.8mm (0.50") CORNER RADIUS ( r ) mm (inch)0.397 (1/64) DIMENSION H -- DIMENSION g2...
Bearings Info
Inner diameter(mm):
15.00
  Outer diameter(mm):
40.00
  Width(mm):
15.90
  Weight(g):
102.00
In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.305802 C-2Z Yoke-type track rollers 15.00 x 40.00 x 15.90 mm
IKO Separable Roller Follower- Metric, NAST50ZZUUR, Crowned OD, Double Sealed 50 mm Bore, 90 mm OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)38900 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)50 SHAFT DIA G6 FIT (MM)-0.009 to -0.025 SIDE PLATE...
IKO Cam Follower-INCH HD Full Comp Screwdriver Slot DBL Sealed 1-3/8" OD 3/4"W 3/4 - 16 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)23600 STATIC LOAD RATING (N)31700 DIMENSION B 21.0mm (0.83") CORNER RADIUS ( r ) mm (inch)1.588 (1/16) DIMENSION H -- DIMENSION g2...
IKO Cam Follower ECC Collar Caged Screwdriver Slot 26mm OD 12mm W M10 x 1.25 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)5430 STATIC LOAD RATING (N)6890 DIMENSION B 13.2mm max CORNER RADIUS ( r ) mm (inch)0.3 DIMENSION H -- PERMISSIBLE STATIC LOAD (N)6890...
IKO Cam Follower ECC Stud Caged Crowned OD Screwdriver Slot 16mm OD 11mm W M6 x 1 THR, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)3660 STATIC LOAD RATING (N)3650 DIMENSION B 12.2 mm max CORNER RADIUS ( r ) mm (inch)0.3 DIMENSION H -- PERMISSIBLE...
IKO Cam Follower ECC Collar Caged Screwdriver Slot 22mm OD 12mm W M10 x 1.25 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)5430 STATIC LOAD RATING (N)6890 DIMENSION B 13.2mm max CORNER RADIUS ( r ) mm (inch)0.3 DIMENSION H -- PERMISSIBLE STATIC LOAD (N)6890...
