IKO Separable Roller Follower- Metric, NAST20ZZUU, Double Sealed, 20 mm Bore, 47 mm OD, Product Specifications BRAND IKO DYNAMIC LOAD RATING (N)19400 OUTER RING CORNER RADIUS MIN. MM (INCH)3 RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)20 SHAFT DIA G6 FIT (MM)-0.007 to -0.020 SIDE PLATE OD (A) MM (INCH)38 INNER RING...
IKO Cam Follower ECC Collar Caged Crowned OD Hex Hole DBL Sealed 90mm OD 35mm W M30 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)45400 STATIC LOAD RATING (N)85100 DIMENSION B 37mm max CORNER RADIUS ( r ) mm (inch)1 DIMENSION H 17mm...
IKO Cam Follower ECC Collar Full Comp Hex Hole DBL Sealed 26mm OD 12mm W M10 x 1.25 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)9570 STATIC LOAD RATING (N)14500 DIMENSION B 13.2mm max CORNER RADIUS ( r ) mm (inch)0.3 DIMENSION H 4mm PERMISSIBLE...
IKO Separable Roller Follower- Metric, NAST12ZZUU, Double Sealed, 12 mm Bore, 32 mm OD, Product Specifications BRAND IKO DYNAMIC LOAD RATING (N)10500 OUTER RING CORNER RADIUS MIN. MM (INCH)2.5 RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)12 SHAFT DIA G6 FIT (MM)-0.006 to -0.017 SIDE PLATE OD (A) MM (INCH)25.5 INNER RING...
IKO Cam Follower ECC Collar Caged Hex Hole DBL Sealed 35mm OD 18mm W M16 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)12000 STATIC LOAD RATING (N)18300 DIMENSION B 19.6mm max CORNER RADIUS ( r ) mm (inch)0.6 DIMENSION H 6mm PERMISSIBLE STATIC...
IKO Separable Roller Follower- Metric, NAST30ZZUU, Double Sealed, 30 mm Bore, 62 mm OD, Product Specifications BRAND IKO DYNAMIC LOAD RATING (N)30500 OUTER RING CORNER RADIUS MIN. MM (INCH)4 RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)30 SHAFT DIA G6 FIT (MM)-0.007 to -0.020 SIDE PLATE OD (A) MM (INCH)50.5 INNER RING...
IKO Cam Follower ECC Collar Caged Crown OD Screwdriver Slot DBL Sealed 35mm OD 18mm W M16 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)12000 STATIC LOAD RATING (N)18300 DIMENSION B 19.6mm max CORNER RADIUS ( r ) mm (inch)0.6 DIMENSION H --...
IKO Cam Follower ECC Stud Caged Screwdriver Slot 35mm OD 18mm W M16 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)12000 STATIC LOAD RATING (N)18300 DIMENSION B 19.6 mm max CORNER RADIUS ( r ) mm (inch)0.6 DIMENSION H -- PERMISSIBLE STATIC LOAD...
Bearings Info
Inner diameter(mm):
17.00
  Outer diameter(mm):
47.00
  Width(mm):
17.50
  Weight(g):
161.00
In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.305703 C-2Z Yoke-type track rollers 17.00 x 47.00 x 17.50 mm
IKO Cam Follower ECC Collar Full Comp Hex Hole 35mm OD 18mm W M16 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)20700 STATIC LOAD RATING (N)37600 DIMENSION B 19.6mm max CORNER RADIUS ( r ) mm (inch)0.6 DIMENSION H 6mm PERMISSIBLE STATIC LOAD...
IKO Separable Roller Follower- Metric, NAST35ZZUU, Double Sealed, 35 mm Bore, 72 mm OD, Product Specifications BRAND IKO DYNAMIC LOAD RATING (N)32400 OUTER RING CORNER RADIUS MIN. MM (INCH)4 RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)35 SHAFT DIA G6 FIT (MM)-0.009 to -0.025 SIDE PLATE OD (A) MM (INCH)53.5 INNER RING...
IKO Cam Follower ECC Stud Caged Hex Hole 26mm OD 12mm W M10 x 1.25 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)5430 STATIC LOAD RATING (N)6890 DIMENSION B 13.2 mm max CORNER RADIUS ( r ) mm (inch)0.3 DIMENSION H 4mm PERMISSIBLE STATIC LOAD...
IKO Cam Follower ECC Collar Full Comp Crown OD SCDR Slot DBL Sealed 35mm OD 18mm W M16 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)20700 STATIC LOAD RATING (N)37600 DIMENSION B 19.6mm max CORNER RADIUS ( r ) mm (inch)0.6 DIMENSION H...
IKO Separable Roller Follower- Metric, NAST8ZZUU, Double Sealed, 8 mm Bore, 24 mm OD, Product Specifications BRAND IKO DYNAMIC LOAD RATING (N)5650 OUTER RING CORNER RADIUS MIN. MM (INCH)2.5 RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)8 SHAFT DIA G6 FIT (MM)-0.005 to -0.014 SIDE PLATE OD (A) MM (INCH)17.5 INNER RING...
IKO Separable Roller Follower- Metric, NAST6ZZUUR, Crowned OD, Double Sealed, 6 mm Bore, 19 mm OD, Product Specifications BRAND IKO BEARING STYLE Crowned OD DYNAMIC LOAD RATING (N)4160 OUTER RING CORNER RADIUS MIN. MM (INCH)-- RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)6 SHAFT DIA G6 FIT (MM)-0.005 to -0.014 SIDE PLATE...
IKO Separable Roller Follower- Metric, NAST25ZZUU, Double Sealed, 25 mm Bore, 52 mm OD, Product Specifications BRAND IKO DYNAMIC LOAD RATING (N)20800 OUTER RING CORNER RADIUS MIN. MM (INCH)3 RETAINERPressed Steel BORE DIAMETER MILLIMETERS (INCH)25 SHAFT DIA G6 FIT (MM)-0.007 to -0.020 SIDE PLATE OD (A) MM (INCH)43 INNER RING...
IKO Cam Follower-INCH HD Full Comp Hex Hole 7/8" OD 1/2"W 7/16 - 20 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)8710 STATIC LOAD RATING (N)12300 DIMENSION B 14.6mm (0.57") CORNER RADIUS ( r ) mm (inch)0.794 (1/32) DIMENSION H 4.762mm (3/16") DIMENSION g2 2.381mm...
IKO Cam Follower ECC Stud Caged Hex Hole DBL Sealed 22mm OD 12mm W M10 x 1.25 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)5430 STATIC LOAD RATING (N)6890 DIMENSION B 13.2 mm max CORNER RADIUS ( r ) mm (inch)0.3 DIMENSION H 4mm PERMISSIBLE...
IKO Cam Follower ECC Collar Full Comp Hex Hole DBL Sealed 30mm OD 14mm W M12 x 1.5 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)13500 STATIC LOAD RATING (N)19700 DIMENSION B 15.2mm max CORNER RADIUS ( r ) mm (inch)0.6 DIMENSION H 6mm PERMISSIBLE...
Bearings Info
Inner diameter(mm):
40.00
  Outer diameter(mm):
80.00
  Width(mm):
24.70
  Weight(g):
629.00
In addition to this article, we can also offer bearings of the brands FAG, KOYO, NSK, SKF, SNR, etc. on request.365208 Yoke-type track rollers 40.00 x 80.00 x 24.70 mm
IKO Cam Follower-INCH HD Full Comp Screwdriver Slot DBL Sealed 11/16" OD 7/16"W 5/16 - 24 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)6340 STATIC LOAD RATING (N)8530 DIMENSION B 12.8mm (0.50") CORNER RADIUS ( r ) mm (inch)0.397 (1/64) DIMENSION H -- DIMENSION g2...
IKO Cam Follower ECC Collar Full Comp Hex Hole DBL Sealed 22mm OD 12mm W M10 x 1.25 THR, Product Specifications BRAND IKO BEARING STYLE Cylindrical OD DYNAMIC LOAD RATING (N)9570 STATIC LOAD RATING (N)14500 DIMENSION B 13.2mm max CORNER RADIUS ( r ) mm (inch)0.3 DIMENSION H 4mm PERMISSIBLE...
