NATV20-PP-A Track rollers bearings Dimensions Width, outer ring C 24 mm Outside diameter of thrust washer d2 36.50 mm Minimum chamfer dimension rmin 1 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 42,500 N Speed on permanent grease lubrication nD G 1,300 1/min Basic...
KR62-PP Stud type track rollers bearings Main Dimensions & Performance Data Speed on permanent grease lubrication nD G 1,900 1/min Basic static load rating, radial C0r 48,500 N Width B 80 mm Outside diameter D 62 mm Fatigue load limit, radial Cur 7,000 N Basic dynamic load rating, radial Cr...
KR16-NMT Stud type track rollers bearings Dimensions Maximum witdh of thrust washer B1 12.20 mm Thread length IG 8 mm Stop diameter of thrust washer d2 12.50 mm Protrusion outer ring to thrust washer C1 0.60 mm Bolt/stud length effectively B2 16 mm Radius of outer ring outside profile R...
KRV40-PP Stud type track rollers bearings Dimensions Witdh of thrust washer B1 21.60 mm Thread length IG 19 mm Diameter lubrication hole ds 3 mm Minimum chamfer dimension rmin 1 mm Width, outer ring C 20 mm Bolt/stud length effectively B2 36.50 mm Width of flats W 8 mm Thread...
LR5305-2HRS-TVH-XL Track rollers bearings Dimensions Radius of outer ring outside profile R 500 mm Diameter of thrust washer d2 37.60 mm Minimum chamfer dimension rmin 1.10 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 22,500 N Fatigue load limit, radial Cur 1,140 N Basic...
KR22-X Stud type track rollers bearings Dimensions Maximum witdh of thrust washer B1 13.20 mm Width of flats W 5 mm Thread M10X1 Minimum chamfer dimension rmin 0.30 mm Width, outer ring C 12 mm Radius of outer ring outside profile R 500 mm Thread length IG 12 mm Stop...
LR5206-X-2Z-TVH-XL Track rollers bearings Dimensions Diameter of thrust washer d2 40.30 mm Minimum chamfer dimension rmin 1 mm Radius of outer ring outside profile R 500 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 22,000 N Fatigue load limit, radial Cur 1,140 N Basic...
ZL5203-DRS Track rollers bearings Dimensions Maximum witdh of thrust washer B1 21.50 mm Thread length (inner) lg 15 mm Minimum chamfer dimension rmin 0.60 mm Protrusion outer ring to thrust washer C1 3.50 mm Length total B4 37.50 mm Radius of outer ring outside profile R 500 mm Thread inside...
LR5306-2Z-TVH-XL Track rollers bearings Dimensions Minimum chamfer dimension rmin 1.10 mm Radius of outer ring outside profile R 500 mm Diameter of thrust washer d2 44.40 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 27,000 N Fatigue load limit, radial Cur 1,520 N Basic...
LR5207-2Z-TVH-XL Track rollers bearings Dimensions Diameter of thrust washer d2 47 mm Minimum chamfer dimension rmin 1.10 mm Radius of outer ring outside profile R 500 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 22,200 N Fatigue load limit, radial Cur 1,450 N Basic...
KRV62-PP Stud type track rollers bearings Dimensions Witdh of thrust washer B1 30.60 mm Thread length IG 25 mm Diameter lubrication hole ds 4 mm Minimum chamfer dimension rmin 1 mm Width, outer ring C 29 mm Bolt/stud length effectively B2 49.50 mm Width of flats W 14 mm Thread...
NATV35-PP-A Track rollers bearings Dimensions Width, outer ring C 28 mm Outside diameter of thrust washer d2 58 mm Minimum chamfer dimension rmin 1.10 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 62,000 N Speed on permanent grease lubrication nD G 750 1/min Basic...
KRE62-PP Stud type track rollers bearings Dimensions Witdh of thrust washer B1 30.60 mm Width, eccentric Be 22 mm Nominal dimension for hexagonal socket W 14 mm Thread M24X1,5 Stop diameter of thrust washer d2 44 mm Protrusion outer ring to thrust washer C1 0.80 mm Distance to lubrication hole...
LR5207-2HRS-TVH-XL Track rollers bearings Dimensions Diameter of thrust washer d2 47 mm Minimum chamfer dimension rmin 1.10 mm Radius of outer ring outside profile R 500 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 22,200 N Fatigue load limit, radial Cur 1,450 N Basic...
LR5204-2Z-TVH-XL-C3 Track rollers bearings Dimensions Diameter of thrust washer d2 29.20 mm Minimum chamfer dimension rmin 1 mm Radius of outer ring outside profile R 500 mm Main Dimensions & Performance Data Permissible dynamic load outer ring, radial Fr per 10,200 N Fatigue load limit, radial Cur 660 N Basic...
